Vertical/Horizontal Muti-stage Pumps

■ Max grain size: 0.2mm

■ Max solid conntent: 0.1%

■ Max fluid temperature: 40℃

■ PH scope of liquid: 6-8

■ Liquid temperature:

■ Low temperature: -20 ~ +70 ℃

■ Standard model: +15 ~ +70 ℃

■ High temperature: +70 ~ +104 ℃

■ Max. environmental temperature: +50 ℃

■ Max. working pressure 8 bar

1. Liquid temperature: +2℃~+100℃
2. Maximum ambient temperature: +40℃
3. Maximum system pressure: 10bar
4. Protection level: IP44
5. Mains connection: 220V/50Hz
6. Insulation class: H
7. Pumped liquid characteristics: clean, free from solids and mineral oils, non-toxic, chemically neutral, close to the characteristics of water
8. Installation: the motor shaft must be kept in horizontal direction
9. pH: 6.5 to 8.5

1 liquid temperature range :2-110 ℃

2 Power supply: Rated voltage supply 220V, frequency 50Hz, single phase

3 Motor: Thermal protector tailored

4 Material: cast iron, PP, ceramics

1 liquid temperature range :2-110 ℃

2 Power supply: Rated voltage supply 220V, frequency 50Hz, single phase

3 Motor: Thermal protector tailored

4 Material: cast iron, PP, ceramics

■Max Temperature of fluid up to +80℃

■Max Pressure 10bar

■Max Ambient Temperature up to 40℃

■ Maximum Operating Pressure: 8 Bar.
■  Maximum Ambient Temperature: +40℃ .
■ Liquid Temperature Up To +90℃ .
■ Maximum Altitude +1000m.

■ Maximum Operating Pressure: 8 Bar.
■  Maximum Ambient Temperature: +40℃ .
■ Liquid Temperature Up To +90℃ .
■ Maximum Altitude +1000m.

■  Max. Working Pressure 6 Bar

■  Liquid Temperature Up To 80

■  Ambient Temperature Up To 40

■  Total Suction Lift Up To 8 Mt.

■  Continuous Duty

■  Max. working pressure 6 bar

■  Liquid temperature up to 80

■  Ambient temperature up to 40

■  Total suction lift up to 8 mt.

■  Continuous duty
