OPERATING LIMITS
- Suction lift up to 6-8m with foot valve.
- Maximum operating pressure: 8 bar.
- Maximum ambient temperature: +40℃ .
- Liquid temperature up to +90℃ .
- Maximum altitude +1000m.
PRODUCTION STANDARD
- IEC 60034-1 - IEC 335-1
- IEC 34-1 - ISO 2548

DESIGN FEATURES
- Pump body: cast iron.
- Impeller: Brass.
- Motor shaft: AISI1045.
- Mechanical seal: NBR/Graphite/Ceramic.
- Internal thermal protector.

MOTOR
- Single phase power supply with capacitor
permanently activated.
- Insulation class: B
- Protection: IP44
- Speed of rotation:2850rpm
- Continuous duty: S1
