OPERATING LIMITS
- Suction lift up to 6-8m with foot valve.
- Maximum operating pressure: 8 bar.
- Maximum ambient temperature: +40℃ .
- Liquid temperature up to +90℃ .
- Maximum altitude +1000m.

DESIGN FEATURES

- Pump body: cast iron.
- Impeller: Brass or PPO or "General Electric".
- Motor shaft: AISI1045.
- Mechanical seal: NBR/ Graphite/Ceramic.
- Internal thermal protector.

SPECIAL FEATURES ON REQUEST
- Stainless steel welding shaft.
- AISI420/AISI304/AISI316 stainless steel shaft.
- FPM/EPDM/SIC/WC mechanical seal.
- Other voltage and frequency.
- Three phase power

PRODUCTION STANDARD

- IEC 60034-1 - IEC 335-1
- IEC 34-1 - ISO 2548

MOTOR
- Single phase power supply with capacitor
permanently activated.
- Insulation class: B
- Protection: IP44
- Speed of rotation:2850rpm
- Continuous duty: S1
