OPERATING LIMITS
- Suction Lift Up To 6-8m With Foot Valve.
- Maximum Operating Pressure: 8 Bar.
- Maximum Ambient Temperature: +40℃ .
- Liquid Temperature Up To +90℃ .
- Maximum Altitude +1000m.

DESIGN FEATURES

- Pump Body: Cast Iron.
- Impeller: Brass Or PPO Or "General Electric".
- Motor Shaft: AISI1045.
- Mechanical Seal: NBR/ Graphite/Ceramic.
- Internal Thermal Protector.

SPECIAL FEATURES ON REQUEST
- Stainless Steel Welding Shaft.
- AISI420/AISI304/AISI316 Stainless Steel Shaft.
- FPM/EPDM/SIC/WC Mechanical Seal.
- Other Voltage And Frequency.
- Three Phase Power

PRODUCTION STANDARD

- IEC 60034-1 - IEC 335-1
- IEC 34-1 - ISO 2548

MOTOR
- Single Phase Power Supply With Capacitor
Permanently Activated.
- Insulation Class: B
- Protection: IP44
- Speed Of Rotation:2850rpm
- Continuous Duty: S1
