TECHNICAL DATA:

1.Starting Pressure: 1.5bar Or 2.2bar

2.Max Rated Current: 10A

3.Max Allowable Pressure: 10bar

4.Rated Voltage: 110V Or 220V

5.Frequency: 50/60HZ

6.Max Ambient Temperature:40℃

7.Max Liquid Temperature:60℃

8.Protection Degree: IP65

DESCRIPTIONS:

1.Stop And Start The Pump Automatically

2. Stop The Pump In The Case Of Water Shortage

3.After Power Cut Off, It Can Restart The Pump Automatically When The Power On

4.Forced Start

5.Joint Screw: G1"Male

OPTIONAS:

Optional Models And Function

PC-10A:Starting Pressure Is Adjustable During Installation, Adjustment Range:1.5bar-3.0bar.

PC-10B:Automatic Restart After Water Shortage, The Restart Interval Time Is 8S,30S,1minute,10minutes,30 Minutes,1 Hour,2 Hour…

The Above 2 Options Function Can Be Achieved At The Same Time, Or You Can Choose Just One

2.Color.

3.G1"Plastic Pipe Joint For A Quick Connection To Water Pump.

4.Power Cable Length

Voltage:AC 220V/110V
Frequency:50/60Hz
Max Current:10A
Max Power:1.1 kW
Start Pressure:0.8 1.5 2.2bar
Max Working/Pressure: 10bar
Jointscrew :G1
Protection/Grade:IP65
Temperature:90℃
Packing Size(cm):53×44×27
PCS/CTN:12
N.W.(kgs):10.68
G.W.(kgs) :13.36
