OPERATING LIMITS
- Suction Lift Up To 9m With Foot Valve.
- Maximum Operating Pressure: 8 Bar.
- Maximum Ambient Temperature: +40℃ .
- Liquid Temperature Up To +60℃ .
- Maximum Altitude +1000m.
DESIGN FEATURES
- Pump Body: Cast Iron.
- Impeller: Brass Or PPO Or "General Electric".
- Ejector Union: PPO Or "General Electric".
- Internal Thermal Protector.
- Motor Shaft: AISI1045.
- Mechanical Seal: NBR/Graphite/Ceramic.

SPECIAL FEATURES ON REQUEST
- Stainless Steel Welding Shaft.
- AISI420/AISI304/AISI316 Stainless Steel Shaft.
- FPM/EPDM/SIC/WC Mechanical Seal.
- Other Voltage And Frequency.
- Three Phase Power.

PRODUCTION STANDARD
- IEC 60034-1 - IEC 335-1
- IEC 34-1 - ISO 2548

MOTOR
- Pump Body: Cast Iron.
- Impeller: Brass Or PPO Or "General Electric".
- Ejector Union: PPO Or "General Electric".
- Motor Shaft: AISI1045.
- Mechanical Seal: NBR/ Graphite/ Ceramic.
