OPERATING LIMITS
- Suction lift up to 9m with foot valve.
- Maximum operating pressure: 8 bar.
- Maximum ambient temperature: +40℃ .
- Liquid temperature up to +60℃ .
- Maximum altitude +1000m.
DESIGN FEATURES
- Pump body: cast iron.
- Impeller: Brass or PPO or "General Electric".
- Ejector union: PPO or "General Electric".
- Internal thermal protector.
- Motor shaft: AISI1045.
- Mechanical seal: NBR/Graphite/Ceramic.

SPECIAL FEATURES ON REQUEST
- Stainless steel welding shaft.
- AISI420/AISI304/AISI316 stainless steel shaft.
- FPM/EPDM/SIC/WC mechanical seal.
- Other voltage and frequency.
- Three phase power.

PRODUCTION STANDARD
- IEC 60034-1 - IEC 335-1
- IEC 34-1 - ISO 2548

MOTOR
- Pump body: cast iron.
- Impeller: Brass or PPO or "General Electric".
- Ejector union: PPO or "General Electric".
- Motor shaft: AISI1045.
- Mechanical seal: NBR/ Graphite/ Ceramic.
